WEICHAI

Primary and Middle School Bus JS6111XCE

最大流量 L/min

额定流量 L/min

额定压力 bar

产品概述

Safety as the foundation; Optimized visibility and lower wind resistance; Approachable front fascia with thoughtful details; Rear styling balancing safety and space; Virtual verification for technical assurance.

产品优势

Robust body for comprehensive protection: High-strength diamond-shaped closed ring combined with front-to-rear steel longitudinal beams, and a 5 mm thick steel plate bumper to disperse impact pressure.

High-strength frame for upgraded safety: Side pillars made of 700 MPa high-strength steel, increasing frame strength by 2-3 times.

Anti-intrusion floor with rapid emergency exit: The floor is over 1 meter above the ground, and the emergency door can be opened via the AUS switch on the dashboard to enhance evacuation efficiency.

Child-centric safety details: The distance from the seat cushion to the lower edge of the window is 0.4 meters, featuring thickened padded seats and armrests; The rear emergency door has a net width of 885 mm, with optional one-touch emergency side-window glass breakers.

Intelligent fire protection and anti-forgetfulness system: Automatic fire extinguisher in the engine compartment and an upgraded anti-forgetfulness button to eliminate safety hazards.

Intelligent maintenance for full-journey support: Easy maintenance access, equipped with telematics technology, supporting full-process tracking and remote diagnostics.

产品规格

Name

Vehicle Length (mm)

Passenger Capacity

Floor Configuration

Engine Power (kW)

Engine Displacement (ml)

JS6111XCE

10570/10610

24-56

Flat floor

140

4088

备注:产品参数及图片仅供参考;如有变动,不另行通知。
