WEICHAI

WP4.6N Engine for Road Roller

Adapted for 13–24t road rollers

99-129/135-175

功率范围 kW/Ps

680/1400-1700

最大扭矩/转速 N·m / r/min

产品概述

With a displacement of 4.58 L and a power output ranging from 99 to 129 kW, it enhances performance and competitiveness, making it suitable for 13–24t road rollers.

产品优势

Adaptability: Meets operational requirements from -25℃ to 50℃; Normal operation at an altitude of 4,500 m.

Power performance: High low-speed torque with a maximum of 680 N·m, strong acceleration, and a 5% improvement in power performance.

Economy: Expanded optimal fuel consumption map range, with fuel consumption under common operating conditions at least 5% lower than competing products.

Reliability: Features modular oil/fuel filters and an integrated cylinder head design, with a B10 life exceeding 20,000 h.

Comfort: Adopts rear gear train, noise-reducing flywheel housing, and a secondary balancing mechanism for low vibration and low noise.

产品规格

功率范围 kW/Ps
99-129/135-175
最大扭矩转速 N·m / r/min
680/1400-1700
排放标准
Stage ⅢA/Stage V
燃料
Diesel
发动机型式
In-line
气缸数
4
气门数
4
排量 L
4.58
进气方式
Turbocharged and intercooled
发动机尺寸(长×宽×高) mm
1140×806×1174
G重量 kg
450

备注:产品参数及图片仅供参考;如有变动,不另行通知。

型谱表

Model

Rated power/speed (kW/rpm)

Peak torque/speed (N·m/rpm)

Displacement (L)

Emission standard

Technical route

Target applications

Number of valves

WP4.6NG175E301

129/2200

680/1400-1700

4.58

Stage ⅢA

CR

13–14t single-drum road roller, 14–18t double-drum road roller

4

WP4.6NG135E670

99/2200

630/1400

4.58

Stage V

DOC+DPF+SCR

24t pneumatic tire road roller

4

WP4.6NG150E672

111/2200

600/1500

4.58

Stage V

DOC+DPF+SCR

14t single-drum road roller

4
