产品概述
V-type, 16-cylinder, four-stroke, turbocharged, water-air intercooled, displacement of 87.5 L, rated power of 2800 kW, rated speed 1800 rpm, maximum torque/speed of 15720 N·m / 1700 rpm.
产品优势
Comprehensive fuel consumption is 8 g/kW·h lower than competing products, reducing operating costs.
Features a flanged cylinder block and double-sided tension bolts, with optimized front and rear end stiffness of the cylinder block to improve engine reliability; overhaul interval of 20000 h, and maintenance interval of 500 h.
High and low temperature dual-stage cooling, operating ambient temperature of ±50℃.
Weichai's proprietary powertrain optimization technology for large-scale mining trucks reduces overall unit vibration and torsional vibration stress on the motor shaft.
产品规格
备注：产品参数及图片仅供参考；如有变动，不另行通知。
型谱表
|
Model |
Rated power/speed (kW/rpm) |
Peak torque/speed (N·m/rpm) |
Displacement (L) |
Emission standard |
Technical route |
Target applications |
Number of valves |
|
16M55G3350E305 |
2461/1800 |
14000/1600 |
87.5 |
China Non-road Stage III |
Common rail |
360t dump truck |
4 |
|
16M55G3550E305 |
2610/1800 |
15000/1700 |
87.5 |
China Non-road Stage III |
Common rail |
360t dump truck |
4 |
|
16M55G3800E305 |
2800/1800 |
15720/1700 |
87.5 |
China Non-road Stage III |
Common rail |
360t dump truck |
4 |
