产品概述
The latest product from Weichais H-series platform, with a displacement of 11.5L. Featuring a family-based, modular design concept, it offers high commonality of parts across 11–15L products and utilizes high thermal efficiency technology to achieve ultra-low fuel consumption.
产品优势
Low fuel consumption: Developed based on a 53.09% thermal efficiency diesel engine platform and supported by multiple proprietary technologies, it consumes 2 L/100 km less fuel than products in the same class.
Lightweight design: Lighter in the 11–12L displacement segment, weighing 150 kg less than products in the same class.
Excellent NVH performance: Employs technologies such as floating vibration isolation for the cylinder head cover, zero-backlash gears, and high-damping noise-reduction materials to achieve low noise in common speed ranges.
Powerful performance: Peak torque of 2000 N·m, leading in low-speed high-torque performance with fast transient response for stronger power delivery.
产品规格
备注:产品参数及图片仅供参考;如有变动,不另行通知。
型谱表
|
Model |
Rated power/speed (kW/rpm) |
Peak torque/speed (N·m/rpm) |
Displacement (L) |
Emission standard |
Technical route |
Target applications |
Number of valves |
|
WP12H400E62 |
294/1800 |
2000/900-1300 |
11.5 |
Euro VI |
CR+DOC+DPF+SCR |
Target applications: tourist bus |
4 |
|
WP12H430E62 |
316/1900 |
2000/900-1400 |
11.5 |
Euro VI |
CR+DOC+DPF+SCR |
Target applications: tourist bus |
4 |
|
WP12H400E50 |
294/1800 |
2000/900-1300 |
11.5 |
Euro V |
CR+SCR |
Target applications: tourist bus |
4 |
|
WP12H430E50 |
316/1900 |
2000/900-1400 |
11.5 |
Euro V |
CR+SCR |
Target applications: tourist bus |
4 |
|
WP12H400E30 |
294/1800 |
2000/900-1300 |
11.5 |
Euro III |
CR |
Target applications: tourist bus |
4 |
|
WP12H430E30 |
316/1900 |
2000/900-1400 |
11.5 |
Euro III |
CR |
Target applications: tourist bus |
4 |
