产品概述
Features a high-fault-tolerance and high-reliability hardware limp-home design; Main oil pressure control and selective lubrication technology to increase efficiency and reduce fuel consumption; Fully electronic shift control for convenient vehicle integration
产品优势
Features a high-fault-tolerance and high-reliability hardware "limp-home" design.
Main oil pressure control and selective lubrication technology to increase efficiency and reduce fuel consumption.
Centralized hydraulic module layout for easy testing and maintenance.
Three-circuit torque converter control increases torque capacity and control precision.
Fully electronic shift control for convenient vehicle integration.
Dual-stage oil filtration system to extend lubricant service life.
产品规格
|
Rated Input Power (kW) |
230 |
|
Maximum Input Torque (Nm) |
750 |
|
Maximum Input Speed (rpm) |
4300 |
|
Forward Gears |
6 |
|
Gear Ratio Range |
0.614-3.102,R-4.492 |
|
Length (mm) |
729 |
|
Transmission Weight (kg) |
150 |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
