产品概述
Hande steering axles feature high reliability, lightweight construction, robust sealing of key components, and long-term maintenance-free operation.
产品优势
High reliability: Ultra-low temperature press-fit kingpin to resolve industry-wide kingpin vibration issues; The I-beam fatigue life is over 20% higher than comparable products, with brake fatigue strength far exceeding industry standards.
Lightweight design: Integrated design of components such as steering knuckles, reducing total axle weight by over 10% compared to market counterparts.
Maintenance-free: Key components such as kingpin, tie rod, camshaft, and adjuster are heavily sealed to achieve long-term maintenance-free operation; Integrated wheel-end bearing unit structure is lifetime maintenance-free.
产品规格
|
Rated Load (t) |
5 |
|
Max. Inner / Outer Steering Angle |
45°/35° |
|
I-Beam Drop (mm) |
100/121/133/151 |
|
Brake Specifications |
19.5" Disc |
|
Wheel Bolt Pitch Circle Diameter (mm) |
Ф275 |
|
Target applications |
8–10m New Energy Intercity Buses |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
