产品概述
Steering Axle.
产品优势
High reliability: Ultra-low temperature press-fit kingpin to resolve industry-wide kingpin vibration issues; The I-beam fatigue life is over 20% higher than comparable products, with brake fatigue strength far exceeding industry standards.
Lightweight design: Integrated design of components such as steering knuckles, reducing total axle weight by over 10% compared to market counterparts.
Maintenance-free: Key components such as kingpin, tie rod, camshaft, and adjuster are heavily sealed to achieve long-term maintenance-free operation; Integrated wheel-end bearing unit structure is lifetime maintenance-free.
产品规格
|
Rated Load (t) |
4.3 |
|
Brake Specifications |
320×120/130, 17.5″ disc brake |
|
Rim Specifications |
8.25R16 |
|
Wheel Bolt Pitch Circle Diameter (mm) |
Φ222.25 |
|
Target applications |
12–14t Models for Transport of Fresh Agricultural Products |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
