12M33 Series Industrial Engine

Family-series products, adaptable to various industrial power segments.

Suitable for fire trucks, high-pressure cleaning, low-pressure water pumps, hydraulic pump stations, mud pumps, and air compressors

900-1194

功率范围 kW/Ps

8000/1150

最大扭矩/转速 N·m / r/min

产品手册下载服务图标

服务支持

立即询价产品咨询

/Products & Businesses/Energy & Power/Industrial Power

概述优势规格型谱表

产品概述

The 12M33 engine features a 39.2L displacement with a power range of 900-1194 kW and is applicable to industries such as fire trucks, high-pressure cleaning, low-pressure water pumps, hydraulic pump stations, mud pumps, and air compressors.

产品优势

High reliability: The cylinder block features a cast iron, grid-type structure for enhanced strength; Crankshaft made of high-strength alloy steel

High economy: Equipped with high-flow oil filters as standard to ensure superior filtration precision, providing cleaner fuel and oil, and reducing operating costs.

Easy maintenance: Inspection windows on both sides of the engine block and a family-style design facilitate servicing and maintenance.

产品规格

功率范围 kW/Ps

900-1194

最大扭矩转速 N·m / r/min

8000/1150

排放标准

Zero emission

产品系列

燃料

Diesel

发动机型式

V-type

气缸数/气门数

12/4

缸径 × 行程mm

排量 L

39.2

进气方式

Turbocharged and air-to-air intercooled

压缩比

燃烧系统

发动机尺寸（长X宽X高） mm

2578×1397×1732

G重量 kg

3438

备注：产品参数及图片仅供参考；如有变动，不另行通知。

型谱表

Model	Displacement (L)	Rated power/speed (kW/rpm)	Peak torque/speed (N·m/rpm)	Governing System	Emission standard
12M33V2D0	39.2	1000/1500	8000/1150	Electronic control	Zero emission
12M33V0D0	39.2	900/1900	5150/1400	Electronic control	Zero emission
12M33V4D0	39.2	1007/1900	6166/1400	Electronic control	Zero emission
12M33V6D0	39.2	1194/1900	6533/1600	Electronic control	Zero emission
