| Max. Input Torque | 25000Nm | |
| Max. Input Speed / Speed/direction | 2800rpm / clockwise | |
| Shaft Center Distance | 300mm | |
| Ratio | On -road | Off -road |
| RatioSerial1 | 0.89 | 1.536 |
| RatioSerial2 | 1 | 1.536 |
| Shifting Operation | Type | position |
| Shifting Operation | 3-pneumatic | backward |
| Shifting Operation | 3-mechanism | backward |
| Front Axle Output Operation (or differential lock operation | Pneu. operation with indication switch | |
| Torque Ratio Proportion | 1:2.214\1:2.69\1:3.0(differential is optional) | |
| Air Pressure | 6.5~8 bar | |
| Lubricant Oil(add to oil leveler) | With differential 8.4L | Without differential9.0L |
| Total weight | 365Kg | 345Kg |
| Optional Unit | N200 PTO is optional, ZF8605 oil pump can be connected | |
| Input Flange | DIN180、T180 | |
| Front Axle Output Flange | DIN150、DIN165、T165 | |
| Rear Axle Output Flange | DIN180、T180 | |
