12M55 for Industrial power
The 12M55 series engine has the advantages of small size, light weight, high reliability, good economy, convenient maintenance and good environmental adaptability.
The 12M55 series engine has the advantages of small size, light weight, high reliability, good economy, convenient maintenance and good environmental adaptability.
The 12M55 is a new addition to the new generation high-end engine M55 platform; it covers 1716-2095kW and meets China's non-road stage3 emission requirements.
| Maximum Power | 2850 hp2095 kW |
| Minimum Power | 2335 hp1716 kW |
| Maximum Torque / Speed | 12500/1400 N·m / r/min |
| Emissions | China non-road Stage Ⅲ |
| Series | 12M55 |
| Fuel | Diesel |
| Type | V-type 12-cylinder, four-stroke engine |
| Cylinder Number | 12 |
| Valve Number | 4 |
| Bore | 180 mm |
| Stroke | 215 mm |
| Displacement | 65.65 L |
| Aspiration | Turbocharged and intercooled |
| Compression Ratio | 16.5:1 |
| Combustion System | Electronically controlled high pressure common rail |
| Length | 2958 mm |
| Width | 1544 mm |
| Height | 2616 mm |
| Weight - Net Dry (Basic Operating Engine Without Optional Attachments) | 9550 kg |
Remarks: Product parameters and pictures are for reference only; subject to change without notice.
| Model | PrimePower （kW） |
Speed （rpm） |
Application | Speed Regulation Mode | Emission | Standby Power （kW） |
|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - |
