/Products & Businesses/Commercial Vehicles/Light-duty Truck/NEV Light-Duty Trucks

概述优势规格型谱表

产品概述

High-Efficiency Urban Electric Light-Duty Truck.

产品优势

High-Performance Battery Platform

Covers 100/120/135/140/165 kWh battery platforms, with a maximum comprehensive range exceeding 550 km.

Utilizes CATL/FinDreams battery modules with both liquid cooling and heating for higher energy density and improved safety.

Powerful Performance

Equipped with a Bosch 200 kW motor, delivering strong power and energy efficiency, optimized for various transport operations.

Enhanced Load Capacity

Optional Hande 5-ton/6-ton/8-ton class maintenance-free rear axles.

80/193 high-strength steel straight beam chassis combined with 8+6 leaf springs for a stable and reliable load-bearing structure.

Driving Comfort

2030 mm wide-body cab, with optional high-roof sleeper to meet the rest needs of two occupants.

Multifunction steering wheel with cruise control and optional air-suspension seat for enhanced driving comfort.

Equipped with ABS + ASR (Acceleration Slip Regulation) as standard, with options for AEB and dual driving alerts, ensuring safety through advanced technology.

产品规格

Product Model	Weichai Landking EH
Battery (Capacity Platform)	100/120/135/140/165 kWh capacity platforms (FinDreams/CATL)
Electric Motor (kW/N·m)	Inovance 165 kW/400 N·m, Hande 120 kW/360 N·m, Bosch 200 kW/500 N·m
All-in-One Controller	Inovance/Bosch/Weichai
Rear Axle	5T/6T/8T rated load Hande maintenance-free rear axle
Frame (mm)	180/800 and 193/865 straight beams
Wheelbase (mm)	3360/3600
Brake System	Air brake

备注：产品参数及图片仅供参考；如有变动，不另行通知。
