WEICHAI

625 kVA-825 kVA Standard Land-based Generator Set Series

Suitable for general market, data centers, livestock farming, real estate, factory warehousing, public utilities, oil and mining fields, equipment rental, water and power grid infrastructure, power stations, specialized products, and communication systems

500-660

功率范围/持续功率

Open, Silent

结构形式

产品概述

The 6M33 series land-based generator sets are Weichais premium inline 6-cylinder generator sets, featuring stable power, high reliability, and a wide range of applications; The 6M33 series land-based generator sets offer a power output range of 500-660 kW.

产品优势

High Reliability: Derived from over a century of European engine technology, the generator sets have undergone more than thirty durability and performance tests, ensuring long-lasting durability and superior reliability

High Adaptability: Capable of operating in complex environments including high temperatures, extreme cold, high altitudes, high humidity, and dusty conditions, while maintaining performance with varying fuel qualities

High-Efficiency Power: Features proprietary transient response calibration to ensure robust power output and stability

High Economy: Matched with turbocharging and intercooling to increase air intake and optimize the combustion process, delivering significant fuel savings

产品规格

功率范围kWe
500-660
产品系列
燃料
Diesel
发动机型式
Inline
气缸数
6
缸径 × 行程mm
排量 L
19.6
机组尺寸(敞开式)mm
3881 × 1680 × 2117 (Open type)
重量(开式)kg
5800 (Open type)
结构形式
Open, Silent

备注:产品参数及图片仅供参考;如有变动,不另行通知。

型谱表

Genset Model

Rated speed (rpm)

Standby Power (kVA/kW)

Prime Power (kVA/kW)

Baudouin Engine Model

Cylinders

Bore × Stroke (mm)

Governing System

Emission standard

WPG700*7

1500

700/560

640/512

6M33G715/5

6

150×185

Electronic Governor

Non-Road Emission Exempt

WPG825*7

1500

825/660

750/600

6M33G825/5

6

150×185

Electronic control

Non-Road Emission Exempt

WPG550*76

1800

688/550

625/500

6M33G575/6

6

150×185

Electronic Governor

Non-Road Emission Exempt

WPG600F76

1800

750/600

681/545

6M33G600/6

6

150×185

Electronic Governor

Non-Road Emission Exempt

WPG660*76

1800

825/660

750/600

6M33G660/6

6

150×185

Electronic control

Non-Road Emission Exempt
