产品概述
The 12M55 is a new product based on the next-generation premium M55 platform, with a power output ranging from 2200-2700 kWm, compliant with Non-emission/EPA Tier II standards, and suitable for 2000-2500 kWe generator sets.
产品优势
Emissions: Non-emission/EPA Tier II
High reliability: Cylinder block and cylinder head are made of compacted graphite iron (CGI) for high strength; Design life of 32000 h
High fuel economy: Equipped with a high-pressure common rail (HPCR) system featuring injection pressures up to 2200 bar, it enables multiple-injection strategies for improved fuel atomization and reduced fuel consumption
Excellent serviceability: Full-series modular design ensures high parts commonality and convenient spare parts availability
产品规格
备注：产品参数及图片仅供参考；如有变动，不另行通知。
型谱表
|
Genset Model |
Rated speed (rpm) |
Standby Power (kVA/kW) |
Prime Power (kVA/kW) |
Weichai Engine Model |
Cylinders |
Bore × Stroke (mm) |
Governing System |
Emission standard |
|
WPG2750*7 |
1500 |
2750/2200 |
2500/2000 |
12M55G2750/5 |
12 |
180×215 |
Electronic control |
Zero emission |
|
WPG3000*7 |
1500 |
3000/2400 |
2750/2200 |
12M55G3000/5 |
12 |
180×215 |
Electronic control |
Zero emission |
|
WPG2750*7 |
1500 |
2750/2200 |
2500/2000 |
12M55G8D2/5 |
12 |
180×215 |
Electronic control |
Non-emission/EPA Tier II |
|
WPG3000*7 |
1500 |
3000/2400 |
2750/2200 |
12M55G10D2/5 |
12 |
180×215 |
Electronic control |
Non-emission/EPA Tier II |
|
WPG2250*76 |
1800 |
2813/2250 |
2500/2000 |
12M55G2250/6 |
12 |
180×215 |
Electronic control |
Zero emission |
|
WPG2500*76 |
1800 |
3125/2500 |
2813/2250 |
12M55G2500/6 |
12 |
180×215 |
Electronic control |
Zero emission |
|
WPG2250*76 |
1800 |
2813/2250 |
2500/2000 |
12M55G4D2/6 |
12 |
180×215 |
Electronic control |
Non-emission/EPA Tier II |
|
WPG2500*76 |
1800 |
3125/2500 |
2813/2250 |
12M55G5D2/6 |
12 |
180×215 |
Electronic control |
Non-emission/EPA Tier II |
