WEICHAI

WP17T Engine for Excavator

Adapted for 65–95t excavators

566/770

功率范围 kW/Ps

3300/1200-1600

最大扭矩/转速 N·m / r/min

产品概述

The WP17T engine is based on an all-new development platform, tailored as a dedicated mining power solution for 65–95t excavators, positioning it as the core power source for mining extraction and continuous operation scenarios. Superior power and fuel economy; maximum power of 566 kW, compliant with Stage ⅢA emission standards with no aftertreatment system required, while also meeting Stage V emission standards; adapted for 65–95t excavators.

产品优势

Adaptability: Suitable for operation between -35°C and 50°C at altitudes up to 5000 meters, with a 500 h oil change interval, ensuring low operating costs.

Dynamics: Maximum power of 566 kW, maximum torque of 3300 N·m, providing powerful performance and excellent vehicle adaptability.

Reliability: All components have undergone 800 h of durability testing, making the engine suitable for harsh mining conditions.

Maintenance convenience: Adopts a modular and standardized design for easy maintenance and low repair costs.

产品规格

功率范围 kW/Ps
566/770
最大扭矩转速 N·m / r/min
3300/1200-1600
排放标准
Stage ⅢA, EU Stage Ⅴ
燃料
Diesel
发动机型式
In-line
气缸数
6
气门数
4
排量 L
16.6
进气方式
Turbocharged and intercooled
发动机尺寸(长×宽×高) mm
1520×1083×1345
G重量 kg
1430

备注:产品参数及图片仅供参考;如有变动,不另行通知。

型谱表

Model

Rated power/speed (kW/rpm)

Peak torque/speed (N·m/rpm)

Displacement (L)

Emission standard

Technical route

Target applications

Number of valves

WP17TG770E304

566/1900

3300/1200-1600

16.6

Stage ⅢA

CR

65–95t excavator

4

WP17TG770E620

566/1900

3300/1200-1600

16.6

EU Stage V

CR+DOC+DPF+SCR

65–95t excavator

4
